Our 8.6 inch display offering includes configurations for projects requiring:
600×1600 resolution: A tall display area for vertically arranged information, menus, graphics and user interfaces.
IPS full viewing angle: Consistent viewing from different directions for equipment used by operators in varied positions.
500 cd/m² brightness: A bright display option for indoor environments and applications with challenging ambient light.
RGB interface: A display connection option for compatible embedded systems and display controllers.
Wide operating temperature: The featured model supports operation from -20°C to 70°C.
Slim form factor: A 2.6 mm module thickness for designs with limited installation space.
The featured model, TFT-H086A01ZRIGC5N40, has an 82.18 × 212.85 mm outline and a 76.36 × 203.62 mm active area. Confirm the full mechanical and electrical specifications in the datasheet before design-in.
HotDisplay supports more than display selection. We help customers evaluate the display, connection and integration requirements of their projects.
Display matching: Review screen size, resolution, viewing angle, brightness and operating conditions.
FPC and cable customization: Discuss cable length, routing, connector position and pinout requirements.
Touchscreen integration: Evaluate capacitive or resistive touch options according to the project’s operating environment and user interface.
Cover glass solutions: Discuss cover-glass dimensions and surface treatments such as anti-fingerprint, anti-glare and anti-reflection.
Interface and system evaluation: Check the display interface and controller compatibility with the customer’s host system.
Project support: Assist with specification review, sample evaluation and production planning.
Customization depends on project requirements, technical feasibility and confirmation during engineering review.
Selecting an LCD by diagonal size alone can lead to integration problems. Our approach considers the complete display system:
1. Understand the product design
Review the device type, screen orientation, available installation space, viewing distance and user interaction requirements.
2. Confirm display specifications
Evaluate resolution, active area, brightness, viewing angle and operating temperature against the application’s requirements.
3. Check electrical compatibility
Review the RGB interface, connector, pin assignment, supply voltage and driver requirements against the host controller. The featured model uses a GC9704 driver IC and a 3.3 V supply.
4. Evaluate mechanical and optical integration
Check module dimensions, FPC routing, touch requirements and cover-glass design to reduce fitting and usability issues.
5. Support sample validation
Use samples and the applicable datasheet to verify image performance, system compatibility and mechanical fit before moving toward volume production.
The elongated 8.6 inch format can support a range of equipment designs:
Industrial instruments and meters: Vertical presentation of readings, status indicators and operating menus.
Industrial control equipment: Compact operator interfaces and equipment status displays.
Portable diagnostic devices: Tall screen layouts for data, charts and device controls.
Portable electronic equipment: Space-efficient display integration in handheld or mobile products.
Embedded smart devices: Custom vertical interfaces where a conventional widescreen format is not suitable.
The appropriate display configuration depends on the device’s environment, interface and mechanical design.
Display selection support: Compare display parameters based on real project requirements rather than screen size alone.
Customization options: Discuss FPC, touch, cover glass and interface-related requirements for product integration.
Engineering-focused evaluation: Review electrical, optical and mechanical compatibility before design-in.
Product and technical resources: Access product specifications and datasheets to support engineering assessment.
Project-oriented cooperation: Coordinate sample evaluation and production requirements for your application.
It is a TFT LCD with an elongated screen shape. The featured 8.6 inch model uses a 600×1600 resolution and a 5:2 aspect ratio, making it suitable for interfaces that need more vertical space than a conventional widescreen display.
The featured model has a specified brightness of 500 cd/m². Suitability for outdoor use depends on direct sunlight exposure, cover-glass reflection, viewing angle and the device enclosure. For direct-sunlight applications, discuss the optical requirements before selection.
The featured TFT-H086A01ZRIGC5N40 uses an RGB interface and a 40-pin FPC. Confirm the host controller’s RGB timing, pinout and electrical requirements against the datasheet before connecting the display.
Touchscreen integration can be discussed for projects requiring capacitive or resistive touch. The touch solution, mechanical fit and electrical connection need to be confirmed for the specific design.
Compare the module outline, active area, thickness, FPC position, connector pinout and mounting arrangement with your device design. Request and review the datasheet, and validate the fit with a sample where necessary.
Contact our team with your target quantity, application, required specifications and project schedule. Sample availability, lead time and production arrangements can then be confirmed for your project.
Looking for an 8.6 inch 600×1600 TFT LCD display for an industrial instrument, portable device or embedded system?
Send us your target specifications, interface requirements and mechanical drawings. Our team can help review the display configuration and discuss a suitable solution for your project.
